General Specifications

LOA - 23' 5"
LWL - 20' 0"
BEAM - 8' 6"
DRAFT, Board up - 1' 11"
DRAFT, Board down - 5' 4"
Displacement - 2,450 lbs.
Ballast - 850 lbs. (Internal fixed lead)
Sail area - 248 sq. ft.
Mast height above DWL - 35' 4"
Designer: -- Jim Taylor

Back to the P-23 page

Detail Specifications

Handicap Rating


  Portsmouth 93.6
  PHRF 231


Sail Plan


I (Jib Height) 26.25 ft.
J (Jib Width) 8.33 ft.
E (Mainsail Width) 10.50 ft.
P (Mainsail Height) 26.25 ft.


Sail Area (approximate)


  Total 248 sq. ft.
  Main 138 sq. ft.
  Jib 110 sq. ft.
  Genoa, 155% 169 sq. ft.
  Spin 335 sq. ft.


Battens 5/8 in stock - (quanity, length)


  1 @ 18 in.
  1 @ 24 in.
  2 @ 27 in.


Cockpit Length


  at Seat Height 84 in.


Cabin Headroom


    54 in.

Berth Length


V-Berth -  Centerline 77 in.
V-Berth -  Parallel to hull side 84 in.
Quarter Berth -  starboard side 73.5 in.
Quarter Berth -  port side 138.5 in.


Portable Head


  Thetford Porta Potti Dealer Supplied

Battery Box


    Battery Box std w/o battery

Running Rigging

  DIA - Length
  Main Halyard (Cleat on Mast) 3/8 in. - 53 ft.
  Cockpit Lead 3/8 in. - 67 ft.
  Jib Halyard (Cleat on Mast) 3/8 in. - 49 ft.
  Cockpit Lead 3/8 in. - 63 ft.
  Main Sheet 3/8 in. - 70 ft.
  Jib Sheet 5/16 in. - 40 ft.
  Genoa Sheet 5/16 in. - 50 ft.
  Out Haul 1/4 in. - 15 ft.
  Boom Vang (Factory Opt. Vang) 5/16 in. - 18 ft.
  Jiffy Reef    1/8 in. 20 ft.
  Topping Lift (line)  1/4 in. - 16 ft.
  Topping Lift (wire upper tail) 27 ft. 7 x 19 PVC Covered wire
  Centerboard Pennant Line 1/4 in. - 10 ft.
  Rudder Downhaul 3/16 in. - 4 ft.
  Rudder Lifting Line 3/16 in. - 6 ft.
  Boom Vang 5/16 in. - 18 ft.
  Lifelines 21 ft. 5.50 in.*
  Lifeline Gate 1 ft. 2.75 in.*
  *NOTE: Length may vary on each lifeline and gate - Measure First.

Standing Rigging

  Diameter - and -Length
  Forestay 3/16 in. 1 X 19 - 27 ft. 7 in.
  Upper Shrouds 3/16 in. 1 X 19 - 24 ft. 9 & 5/8 in.
  Lower shrouds 3/16 in. 1 X 19 - 12 ft. 2 & 1/4 in.
  Backstay 5/32 in. 1 X 19 - 30 ft. 10 7/8 in.
  Backstay Bridle 5/32 in. 7 X 19 - 1 ft. 11 & 3/8 in.


Turnbuckles


  5/16 inch with 5/16x clevis pins

Spars


  Mast 29 ft. 4 in.
  Boom 11 ft. 4 in.
  Spreaders 1 ft 10 1/2 in.


Trailer


  Weight 1000 LBS
  Coupling Size 2 in.
  Wheel/Tire Size B-78 X 13  5 Lug
  Load Range B


Shipping Dimensions


P-23   Boat only Boat W/Cradle Boat W/Trailer
 Height     85 in. 91in. 101 in.
Width     102 in. 102 in. 102 in.
Length     299 in. 299 in. 328 in.
Volume     1500.2 c ft. 1606.1 c ft. 1955.7 c ft.
Weight     2450 lbs. 2675 lbs. 3450 lbs.
